The module converts 4 channels of 100Gbps (PAM4) electrical input data to 4 channels of parallel optical signals, each capable of 100Gbps operation for an aggregate data rate of 400Gbps.

On the receiver side, the module converts four 100Gbps channels of parallel optical signals for an aggregate data rate of 400Gbps into four channels of 100Gbps(PAM4) electrical output data. An optical fiber cable with MPO-12 connector can be plugged into the OSFP 400G SR4 module receptacle.

Features

• Up to 106 Gbps data rate per channel by PAM4 modulation
• Support 400GAUI-8 electrical interface
• Integrated 1310nm EML Laser
• DDM function implemented
• Hot-pluggable
• 400Gb/s, MPO-12
• Single +3.3V power supply

The T1-OSFP-NDR-400G-SR4 is a 400Gbps OSFP optical module designed for 50-meter optical communication applications. The module converts 4 channels of 100Gb/s (PAM4) electrical input data to 4 channels of parallel optical signals, each capable of 100Gbps operation for an aggregate data rate of 400Gbps.

On the receiver side, the module converts four 100Gbps channels of parallel optical signals for an aggregate data rate of 400Gbps into four channels of 100Gbps(PAM4) electrical output data.

An MPO-12 optical fiber cable can be plugged into the OSFP 400G SR4 module receptacle. Host FEC is required to support up to 50m fiber transmission.

Features

• Up to 106 Gbps data rate per channel by PAM4 modulation
• Support 400GAUI-4 electrical interface
• Integrated 850nm VCSEL array and PD array
• DDM function implemented
• Hot-pluggable
• Single +3.3V power supply

The T1-QSFP-DD-400G-DR4 is a 400Gb/s Quad Small Form Factor Pluggable-double density (QSFP-DD) optical module designed for 500m optical communication applications. The module converts 8 channels of 50Gb/s (PAM4) electrical input data to 4 channels of parallel optical signals, each capable of 100Gb/s operation for an aggregate data rate of 400Gb/s. Reversely, on the receiver side, the module converts 4 channels of parallel optical signals of 100Gb/s each channel for an aggregate data rate of 400Gb/s into 8 channels of 50Gb/s (PAM4) electrical output data.

An optical fiber cable with an MTP/MPO-12 connector can be plugged into the QSFP-DD DR4 module receptacle. Proper alignment is ensured by the guide pins inside the receptacle. The cable usually cannot be twisted for proper channel-to-channel alignment. Electrical connection is achieved through a QSFP-DD MSA-compliant edge-type connector.

The product is designed with form factor, optical/electrical connection, digital diagnostic interface according to the QSFP-DD Multi-Source Agreement (MSA) Type 2, and to meet the harshest external operating conditions including temperature, humidity, and EMI interference.

Features:

• QSFP-DD MSA compliant
• Parallel 4 optical lanes
• Compliant to IEEE 802.3bs Specficiation
• Up to 500m transmission on single mode fiber (SMF) with FEC
• Operating case temperature: 0 to 70°C
• 8×53.125Gb/s electrical interface (400GAUI-8)
• Data Rate 106.25Gbps (PAM4) per channel
• Maximum power consumption 12W
• MPO-12 connector
• RoHS compliant

The T1-QSFP-DD-400G-DR4+ is a 400Gb/s Quad Small Form Factor Pluggable-double density (QSFP-DD) optical module designed for 2km optical communication applications. The module converts 8 channels of 50Gb/s (PAM4) electrical input data to 4 channels of parallel optical signals, each capable of 100Gb/s operation for an aggregate data rate of 400Gb/s. Reversely, on the receiver side, the module converts 4 channels of parallel optical signals of 100Gb/s each channel for an aggregate data rate of 400Gb/s into 8 channels of 50Gb/s (PAM4) electrical output data.

An optical fiber cable with an MTP/MPO-12 connector can be plugged into the QSFP-DD DR4+ module receptacle. Proper alignment is ensured by the guide pins inside the receptacle. The cable usually cannot be twisted for proper channel-to-channel alignment. Electrical connection is achieved through a QSFP-DD MSA-compliant edge-type connector. The product is designed with form factor, optical/electrical connection, digital diagnostic interface according to the QSFP-DD Multi-Source Agreement (MSA) Type 2, and to meet the harshest external operating conditions including temperature, humidity, and EMI interference.

Features:

• QSFP-DD MSA compliant
• Parallel 4 optical lanes
• Compliant to IEEE 802.3bs Specficiation
• Up to 2km transmission on single mode fiber (SMF) with FEC
• Operating case temperature: 0 to 70°C
• 8×53.125Gb/s electrical interface (400GAUI-8)
• Data Rate 106.25Gbps (PAM4) per channel
• Maximum power consumption 12W
• MPO-12 connector
• RoHS compliant

The T1-QSFP-DD-400G-FR4 is a 400Gb/s Quad Small Form Factor Pluggable-double density (QSFP-DD) optical module designed for 2km optical communication applications. The module converts 8 channels of 50Gb/s (PAM4) electrical input data to 4 channels of CWDM optical signals and multiplexes them into a single channel for 400Gb/s optical transmission. Reversely, on the receiver side, the module optically de-multiplexes a 400Gb/s optical input into 4 channels of CWDM optical signals and converts them to 8 channels of 50Gb/s (PAM4) electrical output data.

The central wavelengths of the 4 CWDM channels are 1271, 1291, 1311, and 1331 nm as members of the CWDM wavelength grid defined in ITU-T G.694.2. It contains a duplex LC connector for the optical interface and a 76-pin connector for the electrical interface. To minimize the optical dispersion in the long-haul system, single-mode fiber (SMF) has to be applied in this module. Host FEC is required to support up to 2km fiber transmission.

The product is designed with form factor, optical/electrical connection, digital diagnostic interface according to the QSFP-DD Multi-Source Agreement (MSA) Type 2, and to meet the harshest external operating conditions including temperature, humidity, and EMI interference.

Features:

• Compliant with 400G-FR4 Technical Specification rev 2.0 (100G Lambda MSA) and 400GBASE-FR4(IEEE802.3cu)
• Compliant with IEEE 802.3bs standard: 400GAUI-8 electrical interface
• Compliant with QSFP-DD MSA HW Rev 5.0
• Type 2 housing with duplex LC connector
• Compliant with QSFP-DD CMIS Rev 4.0
• Maximum power consumption 12 W
• Case operating temperature 0°C to 70°C
• Two-wire serial Interface with digital diagnostic monitoring
• Complies with EU Directive 2011/65/EU (RoHS compliant)
• Class 1 Laser

The T1-QSFP-DD-400G-FR4 is a 400Gb/s Quad Small Form Factor Pluggable-double density (QSFP-DD) optical module designed for 2km optical communication applications. The module converts 8 channels of 50Gb/s (PAM4) electrical input data to 4 channels of CWDM optical signals and multiplexes them into a single channel for 400Gb/s optical transmission.

Reversely, on the receiver side, the module optically de-multiplexes a 400Gb/s optical input into 4 channels of CWDM optical signals and converts them to 8 channels of 50Gb/s (PAM4) electrical output data. The central wavelengths of the 4 CWDM channels are 1271, 1291, 1311, and 1331 nm as members of the CWDM wavelength grid defined in ITU-T G.694.2.

It contains a duplex LC connector for the optical interface and a 76-pin connector for the electrical interface. To minimize the optical dispersion in the long-haul system, single-mode fiber (SMF) has to be applied in this module. Host FEC is required to support up to 2km fiber transmission.

The product is designed with form factor, optical/electrical connection, digital diagnostic interface according to the QSFP-DD Multi-Source Agreement (MSA) Type 2, and to meet the harshest external operating conditions including temperature, humidity, and EMI interference.

Features:

• QSFP-DD MSA compliant
• 4 CWDM lanes MUX/DEMUX design
• 100G Lambda MSA 100G-LR Specification compliant
• Up to 10km transmission on single mode fiber (SMF) with FEC
• Operating case temperature: 0 to 70°C
• 8×53.125Gb/s electrical interface (400GAUI-8)
• Data Rate 106.25Gbps (PAM4) per channel
• Maximum power consumption 12W
• Duplex LC connector
• RoHS compliant

The T1-QSFP-DD-400G-SR4-BD is a 400Gb/s Quad Small Form Factor Pluggable-double density (QSFP-DD) optical module that can support 400Gb/s bit rates. It is a parallel Quad Small Form-factor Pluggable—double density (QSFP-DD) Bi-Direction optical module. The module accepts eight host electrical data and transmits them in two groups of optical bi-directional lanes (each group contains 4 pairs of optical lanes) to allow optical communication over optical multi-mode fibers. Reversely, on the receiver side, the module accepts 8 sets of optical input signals and converts them to 8 channels of electrical data.

An optical fiber with an MPO-12 connector can be plugged into the QSFP-DD module receptacle. Proper alignment is ensured by the guide pins inside the receptacle. The cable usually cannot be twisted for proper channel-to-channel alignment. Electrical connection is achieved through an MSA- compliant 76-pin edge-type connector.

The module operates by a single +3.3V power supply. LVCMOS/LVTTL global control signals, such as Module Present, Reset, Interrupt, and Low Power Mode, are available with the modules. A 2-wire serial interface is available to send and receive more complex control signals, and to receive digital diagnostic information. Individual channels can be addressed and unused channels can be shut down for maximum design flexibility.

The product is designed with form factor, optical/electrical connection, digital diagnostic interface according to the QSFP28 Multi-Source Agreement (MSA), and to meet the harshest external operating conditions including temperature, humidity, and EMI interference. The module offers very high functionality and feature integration, accessible via a two-wire serial interface.

The central wavelengths of the 4 CWDM channels are 1271, 1291, 1311 and 1331 nm as members of the CWDM wavelength grid defined in ITU-T G.694.2. It contains a duplex LC connector for the optical interface and a 76-pin connector for the electrical interface. To minimize the optical dispersion in the long-haul system, single-mode fiber (SMF) has to be applied in this module. Host FEC is required to support up to 2km fiber transmission

The product is designed with form factor, optical/electrical connection and digital diagnostic interface according to the QSFP-DD Multi-Source Agreement (MSA) Type 2. It has been designed to meet the harshest external operating conditions including temperature, humidity and EMI interference.

Features:

• QSFP-DD MSA compliant
• 8×53.125Gb/s electrical interface (400GAUI-8)
• Up to 150m OM5 MMF transmission
• Operating case temperature 0°C to 70°C
• Single 3.3V power supply
• Maximum power consumption 12W
• MPO-12 optical connector
• RoHS-6 compliant

The T1-QSFP-DD-400G-SR8 is a parallel 400Gb/s Quad Small Form Factor Pluggable–double density (QSFP-DD) optical module that provides increased port density and total system cost savings. The QSFP-DD full-duplex optical module offers 8 independent transmit and receive channels, each capable of 53.125Gb/s operation for an aggregate data rate of 400Gb/s on 100 meters of OM3 multi-mode fiber.

An optical fiber cable with an MTP/MPO-16 connector can be plugged into the QSFP-DD SR8 module receptacle. Proper alignment is ensured by the guide pins inside the receptacle. The cable usually cannot be twisted for proper channel-to-channel alignment. Electrical connection is achieved through a QSFP-DD MSA-compliant edge-type connector. The central wavelengths of all 8 parallel lanes are 850nm.

It contains an optical MPO-16 connector for the optical interface and a 60-pin connector for the electrical interface. Host FEC is required to support up to 70m OM3 multi-mode fiber transmission. The product is designed with form factor, optical/electrical connection, digital diagnostic interface according to the QSFP-DD Multi-Source Agreement (MSA) Type 2, and to meet the harshest external operating conditions including temperature, humidity, and EMI interference.

Features:

• QSFP-DD MSA compliant
• 8 parallel lanes one 850nm center wavelength
• Compliant to IEEE 802.3bs Specficiation
• Up to 70m transmission on multi-mode fiber (MMF) OM3 with FEC
• Operating case temperature: 20 to 60°C
• 8×53.125Gb/s electrical interface (400GAUI-8)
• Data Rate 53.125Gbps (PAM4) per channel
• Maximum power consumption 10W
• MPO-16 connector
• RoHS compliant

The T1-QSFP-DD-4X100G-LR is a 400Gb/s Quad Small Form Factor Pluggable-double density (QSFP-DD) optical module designed for 10km optical communication applications. The module converts 8 channels of 50Gb/s (PAM4) electrical input data to 4 channels of parallel optical signals, each capable of 100Gb/s operation for an aggregate data rate of 400Gb/s. Reversely, on the receiver side, the module converts 4 channels of parallel optical signals of 100Gb/s each channel for an aggregate data rate of 400Gb/s into 8 channels of 50Gb/s (PAM4) electrical output data.

An optical fiber cable with an MTP/MPO-12 connector can be plugged into the module receptacle. Proper alignment is ensured by the guide pins inside the receptacle. The cable usually cannot be twisted for proper channel-to-channel alignment. Electrical connection is achieved through a QSFP-DD MSA-compliant edge-type connector.

The product is designed with form factor, optical/electrical connection, digital diagnostic interface according to the QSFP-DD Multi-Source Agreement (MSA) Type 2. It has been designed to meet the harshest external operating conditions including temperature, humidity, and EMI interference.

Features:

• QSFP-DD MSA compliant
• 4 CWDM lanes MUX/DEMUX design
• 100G Lambda MSA 100G-LR Specification compliant
• Up to 10km transmission on single mode fiber (SMF) with FEC
• Operating case temperature: 0 to 70°C
• 8×53.125Gb/s electrical interface (400GAUI-8)
• Data Rate 106.25Gbps (PAM4) per channel
• Maximum power consumption 12W
• MPO-12 connector
• RoHS compliant
